COMPASSO CTC 24/TB
MODEL WITH MULTIFUNCTION HELPER ARM
STANDARD
- Multifunctional Right Helper Arm
- Outside clamping 10" - 22"
- Inside clamping 13" - 24"
- Wheel width 3" - 15"
- Bead breaking force 2800Kg
- " Leverless System " optional
- Outside clamping 10" - 22"
- Inside clamping 13" - 24"
- Wheel width 3" - 15"
- Bead breaking force 2800Kg
- " Leverless System " Optional
PRODUCTS DETAILS
The vertical hexagonal shaft with spring combines with a horizontal support arm in hardened steel to keep the assembly / disassembly head in perfect position.
Pneumatic locking and automated adjustment of the head to allow adequate distance from the rim.
The rubber stops ensure a gentle return to position.
A sliding roller allows for smooth movement of the arm.
The pedals are forged from a lightweight, durable steel and will not corrode over time.
Industrial-grade pneumatic control valves built with high-performance seals and self-lubricating piston guides help make tire changing more efficient and long-lasting.
The helper arm adjustable in three positions, helps in assembly and disassembly operations even with run-flat, sidewall and low profile tire models.
The helper arm is equipped with a powerful lifting disc and a pressure roller.
